Megmeet MV600 Series User Manual

117
(Er.Fbo)
39: Motor over-temperature
(Er.oHL)
40: Reserved
41: Abnormal AI input fault (Er.AIF
abnormal analog input)
42: Inverter module temperature
sampling disconnection protection
(Er.THI)
43: Rectifier module temperature
sampling disconnection protection
(Er.THr)
44: Short circuit of ±10V analog
output power (Er.10v)
45: Abnormal internal over-current
reference (Er.rEF)
46~50: Reserved
Note:
1. Er.drv fault can not be reset
until 10s later;
2. For continuous over-current
less than 3 times (including 3
times), it can not be reset until 6s
later; if it is more than 3 times, it
can not be reset until 200s later;
3. The keyboard displays AL.xxx
in case of any fault (e.g. in case of
the contactor fault, keyboard
displays Er.xxx if there is
protection action, and displays
AL.xxx if continuing running with
alarm)
P97.16
The second
fault type
The second
fault type
The same as P97.15 1 0 × √ *
P97.17
The third
fault type
The third
fault type
The same as P97.15 1 0 × √ *
P97.18
DC bus
voltage at
the 3rd fault
DC bus
voltage at the
3rd fault
0~999V 1V 0V × √ *
P97.19
Actual
current at
the 3rd fault
Actual
current at the
3rd fault
0.0~999.9A 0.1A 0.0A × √ *
P97.20
Running
frequency at
the 3rd fault
Running
frequency at
the 3rd fault
0.00Hz~3000.00Hz 0.01Hz 0.00Hz × √ *
P97.21
Drive
running
status at the
3rd fault
Drive running
status at the
3rd fault
0~FFFFH
The same as P01.17
1 0000 × √ *
