Megmeet MV600 Series User Manual

126
P01.25~P01.28 are used to display the percentage of the process closed loop reference, feedback, error
and output in Group P14 relative to the full range.
The estimated temperature of motor indicates the motor temperature estimated. Temperature display
range: 0~150
℃; precision: 5％.
Indicating the input pulse frequency of terminal X8.
ASR controller output.
Corresponding value of the torque reference command.
The expansion PG1 selects the UVW increment encoder. It is in UVW input status.
This function code is used to display the UVW signal feedback status of the synchronous motor. When
the motor is rotating forward (looking from the motor shaft, it is rotating counterclockwise), A is before B,
the change order of UVW is as follows: 5 1 3 2 6 4 (W means high level, U means low level. For example,
4 means “W=1, V=0 and U=0”). When the motor is rotating reversely, the change order of UVW is as
follows: 3 1 5 4 6 2. This function code can be used to judge whether the encoder wiring is proper. If it
displays 0 or 7, it indicates that the encoder wiring is wrong.
Corresponding position of local PG Z pulse. The value 65535 corresponds to 360°.
The encoder input speed of the expansion PG1.
The encoder input or output speed of the expansion PG2.
The encoder current input pulse number of the expansion PG1.
When the expansion PG is selected as the UVW increment, this function code displays the initial angle
for installing the encoder. When it is selected as resolver, it displays the initial location of the rotation
encoder. The value 65535 corresponds to 360°.
Corresponding position of local PG1 Z pulse. The value 65535 corresponds to 360°.
The current encoder input pulse number of the expansion PG2.
Corresponding position of PG2 Z pulse 0~65535 (0)P01.41
Counter value of expansion PG2 0~65535 (0)P01.40
Corresponding position of PG1 Z pulse 0~65535 (0)P01.39
Corresponding 0.0％
p
osition of PG1 U pulse 0~65535 (0)P01.38
Counter value of expansion PG1 0~65535 (0)P01.37
Speed of expansion PG2 0.00~600.00Hz(0.00Hz)P01.36
Speed of expansion PG1
0.00~600.00Hz(0.00Hz)
P01.35
Corresponding position of local PG Z pulse 0~65535(0)P01.34
UVW input status of Expansion PG1 0~7 (0)P01.33
Torque reference
-300.0~300.0% (0.0%)P01.32
ASR Controller output -300.0~300.0% (0.0%)P01.31
PULSE frequency of terminal X8 0.0~200.00kHz (0.0)P01.30
Estimated temperature of moto
r
0~200℃ (0)P01.29
Process closed loop output
-100.0~100.0%(0.0%)
P01.28
