13
Note: For 75kWG drive or above, DC reactor is included in its standard configuration. The weight of DC
reactor is not included in the gross weight of the Table 1-3. Outline and dimensions of DC reactor are shown
below. For the drive of 355kWG and above, DC reactor is included in its standard configuration.
Diameter of terminal
Enlarged view of terminal
Mounting
hole
Mounting
hole
Fig. 1-6 Outline and dimensions of DC reactor
Table1-4 Mechanical Parameters of DC Reactor
Applicable
drive（kW）
Model of DC reactor
Recommended
size of copper
（mm
2
）
Size（mm）
Gross
weight
（kg）
A B C D E F G H I J
Diameter
of
terminal
75G DCL-0160-UIDH-7908
60 160 100 98 130 95 65 9 215
/
20
φ8 14.5
90G/90P DCL-0180-UIDH-7908 φ10 16
110G/110P DCL-0250-UIDH-7908 100 210 176 115 150 125 84 11 255 30 φ12 25.5
132G/132P JSY-3674
150
200 170
135 171
120
85
10 260 280
30 φ12
28
160G/160P JSY-3449 210 180 130 12 280 320 32
200G/200P
JSY-3066-1
200
220 190
135 171 150 90
12 315 340 40 φ15
40
220G/220P 250
280G/280P
JSY-3067-1 325 145 181 160 95 45
315G/315P
Note
1. Columns B and C in Table 1-4 are the sizes of mounting holes of DC reactor.
2. For the drive of 75kWG~110kWG/110kWP, the DC reactor is packed separately with a wooden box, so the
gross weight includes the weight of the DC reactor and the wooden box.
3. DC reactor should be installed at the bottom of the cabinet if it is to be installed inside a cabinet. The
clearance between reactor and the drive should be at least 35cm, and the reactor should be as far away from
