Table 6-6 Table of digital input terminal functions
Item Function Item Function
0 No function 1 Forward running (FWD)
2 Reverse running (REV) 3 External jog forward running control input
4 External jog reverse running control input 5 Three-wire operation control
6 Multi-stage reference terminal 1 7 Multi-stage reference terminal 2
8 Multi-stage reference terminal 3 9 Multi-stage reference terminal 4
10 Acceleration/deceleration time terminal 1 11 Acceleration/deceleration time terminal 2
12
Main reference frequency pulse input (valid only for X7
or X8)
13
Auxiliary reference frequency pulse input
(valid only for X7 or X8)
14 Frequency increase command (UP) 15 Frequency decrease command (DN)
16 External fault normally open input 17 External fault normally closed input
18 External interrupt normally open contact input 19
External interrupt normally closed contact
input
20 Reference frequency source switching command 21 Reserved
22 External reset (RESET) input 23 Coast to stop input (FRS)
24 Acceleration/deceleration disable command 25 Stop DC braking input command
26 Simple PLC pause command 27 Reserved
28 Clearing the PLC stop memory 29 PID closed loop disabled
30 PID closed loop soft-start disabled 31 PID integral retention
32 PID integral clearing 33 Switching PID adjustment features
34 Main reference frequency source selection 1 35 Main reference frequency source selection 2
36 Main reference frequency source selection 3 37 Switching main set frequency to AI
38 Command source selection 1 39 Command source selection 2
40 Switching command to terminal 41
FWD disabled
42 REV disabled 43 Drive running disabled
44 External stop command 45 Auxiliary set frequency reset
46 Pre-magnetizing command terminal 47
Speed control and torque control switching
terminal
48 Torque direction switching terminal for torque control 49 Torque offset selection terminal
50 AI torque offset retention 51
Pulse input terminal of the torque limit 1
(valid only for X7 or X8)
52
Pulse input terminal of the torque limit 2 (valid only for
X7 or X8)
53
Torque reference pulse input terminal (valid
only for X7 or X8)
54 Zero servo enable terminal 55 Motor 1 and 2 switching terminal
56 Security terminal input 57 Reserved
58 PG speed testing input A (set only for X7) 59 PG speed testing input B (set only for X8)
60 Emergency stop 61~73 Reserved
74
PID reference frequency pulse input (valid only for X7
or X8)
75
PID feedback frequency pulse input (valid
only for X7 or X8)
76~95 Reserved
Any two terminals can not be set as the same function No. (except for the function No. 0)
0: No function
1: Terminal forward running input (FWD)
2: Terminal reverse running input (REV)
3: Terminal jog forward running input
4: Terminal jog reverse running input
