167
The above functions 1~4 are only enabled under the terminal running command reference mode
(P02.02=1); the running command and the jog command are interlocked, that is: the drive will not
respond to the jog command in the running status, and vice versa.
5: Three-wire operation control
It is enabled only under the terminal running command reference mode (P02.02=1), please refer to
P09.08 for the using method.
6: Multi-stage reference terminal 1
7: Multi-stage reference terminal 2
8: Multi-stage reference terminal 3
9: Multi-stage reference terminal 4
When P13.00=0, the multi-stage reference means multi-stage frequency reference.
By combining the ON/OFF options of these function terminals, the maximum of 15-step speed running
curve can be defined.
Table 6-7 Table of multi-speed running options
K
4
K
3
K
2
K
1
Frequency setting
OFF OFF OFF OFF Common running frequency
OFF OFF OFF ON Multi-stage frequency 1
OFF OFF ON OFF Multi-stage frequency 2
OFF OFF ON ON Multi-stage frequency 3
OFF ON OFF OFF Multi-stage frequency 4
OFF ON OFF ON Multi-stage frequency 5
OFF ON ON OFF Multi-stage frequency 6
OFF ON ON ON Multi-stage frequency 7
ON OFF OFF OFF Multi-stage frequency 8
ON OFF OFF ON Multi-stage frequency 9
ON OFF ON OFF Multi-stage frequency 10
ON OFF ON ON Multi-stage frequency 11
ON ON OFF OFF Multi-stage frequency 12
ON ON OFF ON Multi-stage frequency 13
ON ON ON OFF Multi-stage frequency 14
ON ON ON ON Multi-stage frequency 15
When P13.00=1, the multi-stage reference means multi-stage closed loop reference.
The multi-stage closed loop reference selection in Table 6-8 can be realized by selecting the ON/OFF
combination of the multi-stage closed loop terminals 1~4.
