168

Table 6-8 Expression of multi-stage closed loop reference selection

Multi-stage

closed loop

terminal 4

Multi-stage

closed loop

terminal 3

Multi-stage

closed loop

terminal 2

Multi-stage

closed loop

terminal 1

Multi-stage closed loop

reference selection

OFF OFF OFF OFF

The closed loop reference

is determined by P14.02.

OFF OFF OFF ON

Multi-stage closed loop

reference 1

OFF OFF ON OFF

Multi-stage closed loop

reference 2

OFF OFF ON ON

Multi-stage closed loop

reference 3

OFF ON OFF OFF

Multi-stage closed loop

reference 4

OFF ON OFF ON

Multi-stage closed loop

reference 5

OFF ON ON OFF

Multi-stage closed loop

reference 6

OFF ON ON ON

Multi-stage closed loop

reference 7

ON OFF OFF OFF

Multi-stage closed loop

reference 8

ON OFF OFF ON

Multi-stage closed loop

reference 9

ON OFF ON OFF

Multi-stage closed loop

reference 10

ON OFF ON ON

Multi-stage closed loop

reference 11

ON ON OFF OFF

Multi-stage closed loop

reference 12

ON ON OFF ON

Multi-stage closed loop

reference 13

ON ON ON OFF

Multi-stage closed loop

reference 14

ON ON ON ON

Multi-stage closed loop

reference 15

10: Acceleration/deceleration time terminal 1

11: Acceleration/deceleration time terminal 2

When only one motor (motor 1 or motor 2) is controlled, the acceleration/deceleration time 1~4 can be

selected by combining the ON/OFF status of the acceleration/deceleration terminal 1 & 2.
