Megmeet MV600 Series User Manual

31
Type
Terminal
Name Function Specification
Multi-functional
output terminal
Y1
Open collector
output terminal
1 / DO pulse
output terminal
It can be set as the digital
output terminal with multiple
functions and also can be
reused as DO pulse output
terminal, which is selected by
the function code P09.17. For
details, please refer to the
introduction to the functions of
P09.18 or P09.29 in 6.10
“Digital input/output
parameters” (Group P09)
(common terminal: COM).
Opto-isolated output
Maximum operating voltage: 30V
Maximum output current: 50mA
The DO pulse output frequency range
depends on P09.30 and the maximum
value is 50kHz
Y2
Open collector
output terminal
2
It can be set as the digital
output terminal with multiple
functions. For details, please
refer to the introduction to the
functions of P09.19 in 6.10
“Digital input/output
parameters” (Group P09)
(common terminal: COM).
Opto-isolated output
Maximum operating voltage: 30V
Maximum output current: 50mA
Power supply P24
+24V power
supply
To provide +24V power for
external load
Maximum output current: 200mA
