Group P01: Status display parameters
P01.00
Main
reference
frequency
channel
Main
reference
frequency
channel
0: Disabled
1: Digital reference 1: Keyboard
∧∨ reference
2: Digital reference 2: Terminal
UP/DN reference
3: Serial port communication
reference
4: AI analog reference
5: Terminal PULSE reference
6: Internal PLC running
7: Process closed loop PID
8: Multi-speed
9: PLC card or bus reference
(reserved)
1 0 × √ *
P01.01
Main
reference
set
frequency
Main
reference set
frequency
-3000.00~3000.00Hz 0.01Hz
0.00
× √
*
P01.02
Auxiliary
reference
set
frequency
Auxiliary
reference set
frequency
-3000.00~3000.00Hz
0.01Hz 0.00 × √ *
P01.03
Set
frequency
Set
frequency
-3000.00~3000.00Hz 0.01Hz
0.00
× √
*
P01.04
Frequency
command
(after
acceleration
/
deceleration
)
Frequency
command
-3000.00~3000.00Hz 0.01Hz
0.00
× √
*
P01.05
Output
frequency
Output
frequency
-3000.00~3000.00Hz 0.01Hz 0.00 × √ *
P01.06
Output
voltage
Output
voltage
0~480V 1V
0
× √
*
P01.07
Output
current
Output
current
0.0~3Ie 0.1A 0.0 × √ *
P01.08
Torque
current
Torque
current
-300.0~+300.0％ 0.1％ 0.0％
× √
*
P01.09 Flux current Flux current
0~+100.0％ 0.1％ 0.0％
× √
*
P01.10
Output
torque
Output
torque
-300.0~+300.0％ 0.1％ 0.0％
× √
*
