Page #70 background imageLoading...
Page #70 background image
70
P01.11 Motor power Motor power
0.0%~200.0% (relative to the
rated power of the motor)
0.1 0.0
× *
P01.12
Estimated
frequency of
motor
Estimated
frequency of
motor
-650.00~650.00Hz 0.01 0.00 × × *
P01.13
Measured
frequency of
motor
Measured
frequency of
motor
-650.00~650.00Hz
0.01 0.00
××
*
P01.14
High level of
output
(kWh)
Output (kWh)
0~65535*10000kWh 10000kWh 0 × *
P01.15
Low level of
output
(kWh)
Output (kWh) 0~9999kWh 1kWh 0 × *
P01.16 Bus voltage Bus voltage 0~800V 1V 0 × *
P01.17
Operation
state of the
drive
Operation
state of the
drive
0~FFFFH
Bit 0: RUN/STOP
Bit 1: REV/FWD
Bit 2: Running at zero speed
Bit 3: Accelerating
Bit 4: Decelerating
Bit 5: Running at constant speed
Bit 6: Pre-exciting
Bit 7: Tuning
Bit 8: Over-current limiting
Bit 9: DC over-voltage limiting
Bit 10: Torque limiting
Bit 11: Speed limiting
Bit 12: Drive in fault
Bit 13: Speed control
Bit 14: Torque control
Bit 15: Position control
1 0000 × *
P01.18
State of
digital input
terminal
DI terminal
state
0~FFH, 0: off; 1: on
The high-speed pulse
reference will not be refreshed
synchronously
1 00 × *
P01.19
State of
digital
output
terminal
DO terminal
state
0~FH, 0: open; 1: close
The high-speed pulse output will
not be refreshed synchronously
1 0
×
*
P01.20
AI1 input
voltage
AI1 input
voltage
-10.00~10.00V 0.01V
0.00
×
*
P01.21
AI2 input
voltage
AI2 input
voltage
-10.00~10.00V 0.01V
0.00
×
*
P01.22
AI3 input
voltage
AI3 input
voltage
-10.00~10.00V 0.01V
0.00
×
*
