Megmeet MV600 Series - Page 73

73
P02.02
Running
command
channel
selection
Command
channel
selection
0: Keyboard control
1: Terminal control
2: Communication control
3: Bus control (including bus
communication card and PLC
card) (reserved)
1 0
√ √ ○
P02.03
Running
direction
setting
Running
direction
setting
0: Forward running; 1: Reverse
running
1 0 √ √ ○
P02.04
Main
reference
frequency
source
selection
Main
reference
source
selection
0: Digital reference 1: Keyboard
∧∨ reference
1: Digital reference 2: Terminal
UP/DN reference
2: Serial port communication
reference
3: AI analog reference
4: Terminal PULSE reference
5: Internal PLC running
6: Process closed loop PID
7: Multi-speed
8: Expansion bus card reference
1 0 √ √ ○
P02.05
Digital
setting of
main
reference
frequency
Main
reference
frequency
setting
P02.17~P02.16 0.01Hz
50.00
√ √ ○
P02.06
Main &
auxiliary
reference
digital
frequency
control
Main &
auxiliary
reference
frequency
control
Unit place of LED: Main digital
frequency saving control
0: Save when power down
1: Do not save when power down
Tens place of LED: Main digital
frequency control when stop
0: Maintained when stop
1: Reset when stop
Hundreds place of LED: Auxiliary
digital frequency saving control
0: Save when power down
1: Do not save when power down
Thousands place of LED:
Auxiliary digital frequency
control when stop
0: Maintained when stop
1: Reset when stop
Note: The unit and tens places
are only applicable for P02.04=0,
1, 2
hundreds and thousands place
are only applicable for P02.07=1,
1 0000 × √ ○
