74
2, 3
P02.07
Auxiliary
reference
frequency
source
selection
Auxiliary
frequency
source
selection
0: No auxiliary reference
1: Digital reference 1: Keyboard
∧∨ reference
2: Digital reference 2: Terminal
UP/DN reference
3: Serial port communication
reference
4: AI analog reference
5: Terminal PULSE reference
6: Process closed loop PID
7: Expansion bus card reference
1 0 × √ ○
P02.08
Digital
setting of
auxiliary
reference
Digital
auxiliary
reference
0.00~3000.0Hz 0.01Hz
0.00
× √ ○
P02.09
Auxiliary
reference
coefficient
Auxiliary
reference
coefficient
0.00~9.99
Only enabled for P02.07=4~7
0.01 1.00 × √ ○
P02.10
Calculation
of reference
frequency
source
Main/auxiliar
y reference
calculation
0:+
1:-
2:*
3: MAX (main reference, auxiliary
reference)
4: MIN (main reference, auxiliary
reference)
5: sqrt (main reference) + sqrt
(auxiliary reference)
6: sqrt (main reference + auxiliary
reference)
7: Switching between main and
auxiliary reference frequency
source
8: Switching between main
reference frequency source and
(main + auxiliary) reference
frequency source
9: Switching between auxiliary
reference frequency source and
(main + auxiliary) reference
frequency source
1 0 × √ ○
P02.11
Proportion
adjustment
selection of
set
frequency
Frequency
proportion
adjustment
0: Disabled
1: Corresponds to P02.15
2: Corresponds to the current
frequency
1 0 × √ ○
P02.12
Proportion
adjustment
Proportion
adjustment
0.0%~200.0%
0.1％ 100.0％
× √ ○
