Megmeet MV600 Series - Page 77

77
nameplates
P03.18
Stator
resistance
of motor 2
Stator
resistance
R1
0.000~65.000
0.001
Depending
on model
√ √ ×
P03.19
Leakage
inductance
or direct
axis
inductance
of motor 2
Leakage
inductance or
direct axis
inductance of
motor 2
0.0~2000.0 0.1
Depending
on model
√ √ ×
P03.20
Rotator
resistance
or
back-EMF
constant of
motor 2
Rotator
resistance or
back-EMF
constant of
motor 2
0.000~65.000 0.001
Depending
on model
√ √ ×
P03.21
Mutual
inductance
or q-axis
inductance
of motor 2
Mutual
inductance or
q-axis
inductance of
motor 2
0.0~2000.0 0.1
Depending
on model
√ √ ×
P03.22
No-load
current (I0)
of motor 2
No-load
current (I0)
0.1~999.9A 0.1A
Depending
on model
√ √ ×
P03.23
Overload
protection
factor of
motor 2
Overload
protection
factor of
motor 2
20.0~110.0%
Set action level (%) = motor rated
current/ drive rated current × 100
Low speed compensation actual
action level = set action level ×
(output frequency/ 30HZ × 45 +
+55)
Actual converted current of
overload protection = sampling
current/overload protection action
level
0.1% 100.0% √ √ ×
P03.24
Parameter
auto-tuning
Parameter
auto-tuning
0: Disabled
1: Enabled (motor in static status)
2: Enabled (motor in rotate status)
3: Reserved (according to the
nameplate setting)
1 0
√ √ ×
P03.25
Synchronou
s motor
identification
current
Synchronous
motor
Identificatio
n current
0~30% of motor rated current 0
10
√ √ ×
P03.26
Initial angle
for installing
encoder
Initial angle 0~FFFFH
1 0
√
√ ×
P03.27
Initial angle
of encoder Z
Angle of Z
pulse
0~FFFFH 1 0
√
√ ×
