MA-5162-ENG MICRON
+
PISTON ADHESIVE MELTERINSTALLATION
3-11
Connection
Description
Output DO2 XDO3 XDO4
StandBy
+24V Close Close In "STADBY"
GND Open Open No "STANDBY"
Zones in
Temperature OK
+24V Close Close In “ Temperature OK”
GND Open Open No “ Temperature OK”
Machine Ready
+24V Close Close Ready
GND Open Open No Ready
Running
+24V Close Close Pumping
GND Open Open Not Pumping
Alarm
+24V Close Close Alarms
GND Open Open No Alarms
Level
+24V Close Close Level “OK”
GND Open Open Level “No OK”
No Level
+24V Close Close Level “No OK”
GND Open Open Level “OK”
+24V
OUT
1
2
3
CLOSE = 1
OPEN = 0
HMI
DO3
DO4
2 OUT-
1 OUT+
Melter
XDO3
XDO4
2
1
+24V
OUT
1
2
3
CLOSE = 1
OPEN = 0
HMI
DO2
2 OUT-
1 OUT+
Melter
