6. TECHNICAL CHARACTERISTICS
Generals
Tank capacity 5.15 liters 9.7 liters
Pumping rate
29.3 kg/h 7cc/stroke pump (*)
66.0 kg/h 19cc/stroke pump (*)
29.3 kg/h 7cc/stroke pump (*)
66.0 kg/h 19cc/stroke pump (*)
Melting rate 9.0 kg/h (*) 13.5 kg/h (*)
Number of hydraulic outputs 6 (thread 9/16) 6 (thread 9/16)
Temperature range
(optional)
40 to 200 °C (104 to 392 °F)
40 to 230 °C (104 to 446 °F)
40 to 200 °C (104 to 392 °F)
40 to 230 °C (104 to 446 °F)
Temperature control
RTD ±0.5 °C (±1 °F)
Pt-100, Ni-120 or NTC-R
RTD ±0.5 °C (±1 °F)
Pt-100, Ni-120 or NTC-R
Max. working pressure (at 6 bar) 81.6 bar (1183 psi) 81.6 bar (1183 psi)
Max. installation power
(Maximum current allowed is 27A
per phase)
5900 W (2 electrical outputs)
9500 W (4 electrical outputs)
13100 W (6 electrical outputs)
6900 W (2 electrical outputs)
10500 W (4 electrical outputs)
14100 W (6 electrical outputs)
External functions
Inputs
Outputs
Unit On-Off • Standby On-Off •
Activity Control • Pumping On-Off •
Communications On-Off • Electrical
Outputs Inhibition
Standby • Zones Temperature OK •
Machine Ready • Running • Alarm •
Level • No Level
Unit On-Off • Standby On-Off •
Activity Control • Pumping On-Off •
Communications On-Off • Electrical
Outputs Inhibition
Standby • Zones Temperature OK •
Machine Ready • Running • Alarm •
Level • No Level
Electrical requirements
(optional)
(optional)
1N ~ 230V 50/60Hz + PE
3N ~ 400V 50/60Hz + PE
3 ~ 230V 50/60Hz + PE
3 ~ 400V 50Hz + PE with
transformer base
1N ~ 230V 50/60Hz + PE
3N ~ 400V 50/60Hz + PE
3 ~ 230V 50/60Hz + PE
3 ~ 400V 50Hz + PE with
transformer base
Ambient temperature 0 to 40 °C 0 to 40 °C
Dimension (LxWxH)
587 x 341 x 481 mm
587 x 341 x 628 mm (lid open)
671 x 341 x 481 mm
671 x 341 x 760 mm (lid open)
Weight 37.5 kg (empty) 45.7 kg (empty)
(*) Under standard conditions
