Mellanox Technologies Spectrum SN2010 User Manual

Installation
Rev 2.2
28Mellanox Technologies
Figure 13: Installation Options
Step 1. Attach the left and right rack mount rails (A) to the switch, by gently pushing the switch
chassis’ pins through the slider key holes, until locking occurs.
Step 2. Secure the chassis in the rails by screwing 2 flat head Phillips screws (E) in the designated
points with a torque of 1.5±0.2 Nm. See
Figure 14.
Front side
Rear side (FRUs)
1
2
