Installation
Rev 2.2
57Mellanox Technologies
For bring-up of a switch system with Cumulus Linux operating system installed, refer to Section
2.8.2.
2.8.1 Configuring Network Attributes Using Onyx (MLNX-OS)
The procedures described in this chapter assume that you have already installed and powered on
the system according to the instructions in this document. The system comes with a pre-config
-
ured DHCP. If you wish to disable it, refer to “Disable Dynamic Host Configuration Protocol
(DHCP)”. In case a manual configuration is required, please refer to the instructions in Section
2.8.1.1.
2.8.1.1 Manual Host Configuration
To perform initial configuration of the system:
Step 1. Connect a host PC to the Console RJ45 ( ) port of the system, using the supplied har-
ness cable (DB9 to RJ45). Make sure to connect to the Console RJ45 port and not to the
(Ethernet) MGT (
) port.
Step 2. Configure a serial terminal program (for example, HyperTerminal, minicom, or Tera Term)
on your host PC with the settings described in
Table 11. Once you perform that, you should
get the CLI prompt of the system.
Step 3.Login as admin and use admin as password. On the first login, the Onyx (MLNX-
OS) configuration wizard will start.
Step 4. To configure network attributes and other initial parameters to the system, follow the con-
figuration wizard as shown in Table 12.
Table 11 - Serial Terminal Program Configuration
Parameter
Setting
Baud Rate 115200
Data bits 8
Stop bits 1
Parity None
Flow Control None
Table 12 - Configuration Wizard Session
Wizard Session Display Comments
Mellanox configuration wizard
Do you want to use the wizard
for initial configuration? yes
You must perform this configuration the first time you operate
the system or after resetting the system. Type ‘y’ and then press
<Enter>.
Step 1: Hostname? [switch-1] If you wish to accept the default hostname, press <Enter>. Other-
wise, type a different hostname and press <Enter>.
