Figure 64: System Status LEDs - Front and Rear Sides in SN2410
Figure 65: System Status LED in SN2100
Figure 66: System Status LED in SN2010
Both of the System Status LEDs (front and back, if exist) supply identical information.
It may take up to five minutes to turn on the system. If the System Status LED shows
red after five minutes, unplug the system and call your Mellanox representative for
assistance.
Both of these LEDs in the red
ovals show the system’s sta-
tus.
The LED in the read oval is located on
the front panel of SN2100. There are no
LEDs in the rear panel of SN2100.
The LED in the read oval is located on
the front panel of SN2010. There are no
LEDs in the rear panel of SN2010.
