Figure 69: Fan Status LED in SN2410 - Front and Rear Sides
Figure 70: Fan Status LED in SN2100
Figure 71: Fan Status LED in SN2010
Table 17 - Fan Status Front LED Assignments
LED
Behavior
Description Action Required
Solid
Green
All fans are up and running. N/A
Solid Red Error, one or more fans are not operating prop-
erly.
The faulty FRUs should be replaced.
Off System boot N/A
Both of these LEDs in the red ovals
show the fans’ status.
The SN2100 systems have a
front fan LED only.
The SN2010 systems have a
front fan LED only.
