Installation
Rev 2.2
38Mellanox Technologies
2.5.3 Static Rail Kit for SN2740 and SN2410
The following parts are included in the static rail kit (see Figure 12):
• 2x Rack mount rails (A)
• 2x Rack mount blades (B)
• 8x M6 Standard cage nuts¹ ² and 8x M6 Standard pan-head Phillips screws¹ (C)
• 4x Phillips100 DEG F.H TYPE-I ST.ST 6-32 X 1/4 screw with around patch (D).
¹ Other threads are available by special order: M5, 10-32, 12-24
² G-type cage-nut is available by special order.
At least two people are required to safely mount the system in the rack.
By default, the system is sold with the standard-depth rail kit. The short-depth rail kit
can be supplied upon request.
Table 9 - Installation Kit
Kit OPN Rack Size and Rack Depth Range
MTEF-KIT-BP Short (19.7"-23.6" \ 50 to 60 cm)
MTEF-KIT-SP Standard (23.6"-31.5" \ 60 to 80 cm)
