Specifications
Rev 2.2
87Mellanox Technologies
6.3 SN2410 Series
Table 27 - SN2410 Specifications
Feature Value
Mechanical
Size:
43.9mm (H) x 438mm (W) x 394mm (D)
1.72"(H) x 17.24"(W) x 15.5"(D)
Mounting: 19" Rack mount
Weight:
1 PSU weight 6.726kg (14.8 lb)
2 PSU weight 7.526kg (16.6 lb)
Speed: 10/25GbE per port (ports 1-48), 10/25/40/50/56/100GbE per port (ports 49-56)
Connector cage: 48xSFP28 and 8xQSFP28
Environmental Temperature:
Operational: 0° to 40°C
Non-Operational: -40° to 70°C
Humidity:
Operational: 10% - 85% non-condensing
Non-Operational: 10% - 90% non-condensing
Altitude:
3050m
Noise level: 70.9 dB(A)
Regulatory Safety/ EMC: CB, cTUVus, CE, CU, S_Mark, CE, FCC, VCCI, ICES, RCM, BSMI, KCC, CCC
RoHS6
Power
Input Voltage: 100-127Vac 50/60Hz 4.5A; 200-240 50/60Hz 2.9A/ 192-288VDC (not certified)
Global Power Consumption:
40GbE Models -
Typical power with passive cables (ATIS): 165W (same as the 100GbE models)
Max power with optical cables (assuming 2W per each QSFP28 port, and 1W per each SFP28
port): 295.1
100GbE Models:
Typical power with passive cables (ATIS): 165W
Max power with optical cables (assuming 3.5W per each QSFP28 port, and 1.5W per each SFP28
port): 362W
Main Devices CPU: Intel x86 1.40GHZ Dual Core
PCIe: 4x Gen2.0
Switch: Mellanox Spectrum™
Memory:
8GB DDR3 RAM, 32G SSD for systems based on Switch rev. B1 and earlier
8GB DDR3 RAM, 16G SSD for systems based on Switch rev. B2 and higher
Throughput 4Tb/s
