3 Interfaces
3.1 Supported Interfaces
The systems support the following interfaces:
• Data interfaces - Ethernet: 1/10/25/40/50/56/100GbE
• 10/100/1000 MbE speed rates
• USB port (mini USB in SN2100)
• RS232 Console port
• RJ45 management interface(s)
• Reset button
• Status and Port LEDs
In order to review the full configuration options matrix, refer to Table 4, “Management Inter-
faces, PSUs and Fans”.
3.1.1 Data Interfaces
The data interfaces use QSFP28 connectors. The full list of interfaces per system is provided in
Table 3, “Speed and Switching Capabilities”. Each QSFP28 port can be connected with a
QSFP28 cable or connector for 25/40/50/56/100GbE, or 1/10/25GbE when connecting through
Mellanox QSFP28 to SFP28 (Dynamix™ QSA) adapters, hybrid or split cables. The systems
offer support of up to 3.5W transceivers in all QSFP28 ports, and support of up to 1.5W in all
SFP28 ports.
Some QSFP28 ports and SFP28 ports support higher power consumption transceivers, as detailed
in the following table:
Table 14 - High Power/LR4 Transceivers Support
Model Family Ports Maximum High Power Support
SN2700 1, 2, 31, 32
4.5W
a
a. 4.5W high power modules are supported on Onyx (MLNX-OS) from version 3.6.3004 onwards.
SN2740 1, 2, 31, 32
SN2410
1,2,47,48
b
b. SFP28 ports
2.5W
49, 50, 55, 56
4.5W
a
SN2100 1, 2, 15, 16
4.5W
a
SN2010 19,20,21,22
4.5W
a
