NetPerformer Hardware Installation Guide
4-44 Memotec Inc.
► To connect this cable:
1.
Connect one end of the cable to the RJ-45 connector on the interface card.
2. Connect the other end to the RJ-45 connector on the trunk side of the PBX
As an alternative, you can cut it off and punch on a Telco/PTT block termination.
NOTE: You must install a ferrite on each cable connected to an E&M port on an
SDM-9XXX Series unit in all countries.
These ferrites are not provided with
the product package. For instructions, turn to “Installing the Ferrites (EMI Filters)”
on page 3-27.
Caution
For important E&M wiring and grounding considerations, refer to “E&M
Wiring and Grounding” on page 3-24.
