Serial Port and User Equipment Connections
Memotec Inc. 5-7
5.6 Custom Serial Cable Specifications
In the following sections the Ordering part number is required for ordering extra cables.
The Stock number is printed on the cable.
5.6.1 V.35/V.11 Cables
• HD-26 male connector at one end for connection to the NetPerformer serial port
• ISO-2593 female (DCE) or male (DTE) connector at the other end for connection
to the V.35/V.11 equipment
- Use the DCE cable for connection to a male connector on the V.35/V.11
equipment (typically a DTE device).
Ordering part number
161-0893-001, Stock number 502-0940-006.
- Use the DTE cable for connection to a female connector on the V.35/V.11
equipment (typically a DCE device).
Ordering part number
161-0894-001, Stock number 502-0941-006.
5.6.2 TIA-232 (V.24) Cables
• HD-26 male connector at one end for connection to the NetPerformer serial port
• DB-25 female (DCE) or male (DTE) connector at the other end for connection to
the TIA-232 (V.24) equipment
- Use the DCE female cable for connection to a male connector on the TIA-232
(V.24) equipment (typically a DTE device).
Ordering part number
161-0897-001, Stock number 502-0944-006.
- Use the DTE male cable for connection to a female connector on the TIA-232
(V.24) equipment (typically a DCE device).
Ordering part number
161-0898-001, Stock number 502-0945-006.
5.6.3 X.21 Cables
An X.21 cable has a 4-40 screw on the DB-15 connector.
• HD-26 male connector at one end for connection to the NetPerformer serial port
• DB-15 female (DCE) or male (DTE) connector at the other end for connection to
the X.21 equipment
- Use the DCE female cable for connection to a male connector on the X.21
equipment (typically a DTE device).
Ordering part number
161-0895-001, Stock number 502-0942-006.
- Use the DTE male cable for connection to a female connector on the X.21
equipment (typically a DCE device).
Ordering part number
161-0896-001, Stock number 502-0943-006.
