Product Description
Memotec Inc. 4-9
1 Cooling fans (3) 3 -36 to -60 VDC Single Power Supply
2 Ground lug 4 Hot-Swap Redundant DC Power Supply
1+1 (-35 to -60 VDC)
Figure 4-8: Rear View of the SDM-9140 with -48VDC Power Supply Options
Item Details
Base unit chassis, with four slots for interface
cards
“Base Unit Chassis” on page 4-11
Two or eight Ethernet ports (require customer-
supplied LAN cables)
“Ethernet Ports” on page 4-13
One serial port (requires custom serial cable) “Serial Port” on page 5-3
One console port, with console cable “Console Port” on page 4-15
One to two power supplies, with removable
power cable.
“Power Supply” on page 4-17
One rackmount kit “Rackmount Kit” on page 4-18
Table 4-3 Basic Features of the SDM-9140 Unit
