Product Description
Memotec Inc. 4-11
4.6 Base Unit Chassis
4.6.1 SDM-9220/9230 Physical Dimensions
• Width: 42.7 cm (16.8")
• Depth: 31 cm (12.2")
• Height: 8.9 cm (3.5")
• Typical weight: 4.5 kg (10 lb)
4.6.2 SDM-9120 Physical Dimensions
• Width: 42.7 cm (16.8")
• Depth: 31 cm (12.2")
• Height: 4.5 cm (1.75")
• Typical weight: 1.8 kg (4 lb)
4.6.3 SDM-9140 Physical Dimensions
• Width: 42.7 cm (16.8")
• Depth: 36 cm (14.2”)
• Height: 4.5 cm (1.75")
• Typical weight: 4.5 kg (10 lb)
4.6.4 System Status LEDs
Front Panel Three system status LEDs: POWER, STATUS and ALARM, are provided on the front
panel of the SDM-9XXX Series. These LEDs are located on the right side of the unit when
viewed from the front. See “Front View of the SDM-9220/9230 Base Unit” on page 4-5 or
“Front View of the SDM-9140e” on page 4-7.
NOTE: For added convenience, on the SDM-9120/9220/9230 units, the same three
LEDs are provided on the rear panel, below Slot 1. See “Rear View of the SDM-
9220/9230 UAC” on page 4-5.
•POWER (green) goes on when the unit is powered on.
•STATUS (red/amber/green) indicates which program is operating on the unit, as
shown in Table 4-6
.
