Memotec NetPerformer SDM-9140

Product Description
Memotec Inc. 4-5
4.3 SDM-9220/9230 Base Unit
4.3.1 Front View of the SDM-9220/9230 Base Unit
4.3.2 Rear View of the SDM-9220/9230 Base Unit
Figure 4-3: Front View of the SDM-9220/9230
1 Serial number 7 Console port
2 System status LEDs 8 Ground lug
3 Interface card slots 9 ON/OFF switch
4 Ethernet ports (2) 10 AC connector
5 LAN status LEDs 11 Power supply
6 Serial port
Figure 4-4: Rear View of the SDM-9220/9230 UAC
4
52
11
6 7 8
101
3
9
