Hardware Installation
Memotec Inc. 3-15
5. Connect the following adapter for E1-75 operations onto the digital port: RJ-48 to E1-
75 dual BNC adapter cable (Ordering part number: AG2CA0001).
NOTE: Without an adapter, the E1 port will not operate at 75 ohms.
Caution
The adapter and attached BNC coaxial cables require strain relief to
ensure that they do not loosen from the digital port:
-If the unit is mounted in a rack, you must secure the cables to a side
rail using tie-wraps, or support the weight of the cables on a tray
-If the unit is on a table, you must support the weight of the cables
on the table.
The digital port can desynchronize and the unit reset if the full weight of
the BNC coaxial cables is unsupported.
