Hardware Installation
Memotec Inc. 3-33
NOTE: If the PWR LED does not light up or the STATUS LED is red at the end of this
sequence, the unit may be faulty. Contact Technical Support for assistance (see
“Technical Support” on page 1-11). See also “Troubleshooting Tips” on page 6-1.
3 green red off
Bootstrap is running. Preparing to start the
boot sector
4 green amber off
Boot sector is running. Validating the
application
5 green amber amber
Boot sector is running. Decompressing the
application
6 green off
off Application has started from a power-on
red Application has started from a software reset
7 green green
off
Application has started from a power-on; at
least one link is up
red
Application has started from a software reset;
at least one link is up
Stage PWR ST AL
Current Status of the SDM-9XXX Series
Unit
Table 3-4 Front Panel LED States During System Startup
