Product Description
Memotec Inc. 4-31
NOTE: Except for the SDM-9140, you must install a ferrite on each cable
connected to an FXS port on an SDM-9XXX Series UAC unit installed in the
European Union or Russia. These ferrites are not provided with the product
package. For instructions, turn to “Installing the Ferrites (EMI Filters)” on page 3-
27.
FXO Interface
Cards
Ordering part numbers for the SDM-9220/9230:
161-1051-000 for the dual FXO interface card
161-1052-000 for the quad FXO interface card.
Ordering part numbers for the SDM-9120:
161-1351-000 for the dual FXO interface card
161-1352-000 for the quad FXO interface card.
Ordering part numbers for the SDM-9140:
161-1451-000 for the dual FXO interface card
161-1452-000 for the quad FXO interface card.
NOTE: To meet EMI homologation requirements, using the specific cables included with
the SDM-9140 FXO interface card is mandatory.
For the Dual FXO:
- KT-0021369
- Kit, 2 x Cables for FXS or FXO, SDM-9140
- cable: CA-0021855
For the Quad FXO:
- KT-0021370
- Kit, 4 x cables for FSX or FXO, SDM-9140
- cable: CA-0021855
The FXO interface card is a Telco/PTT interface that acts like a standard telephone set (a
two-wire telephone in a loop start circuit). This interface card:
• Provides a Subscriber Line connection to a Central Office or the station side of an
analog PBX.
• Detects ring voltage, closes the loop during off-hook, and opens the loop in an
on-hook condition.
• Generates pulse dial or DTMF tones.
• Dual port interface with 2 RJ-11 female connectors for the dual FXO interface
card.
