AC1200 Wireless Dual Band Gigabit Router
• Common Service - Here lists some common service ports. Select one from the
drop-down list, and the corresponding port number will be filled in the Port field
automatically. For example, if you select HTTP, 80 will be filled in the Port field
automatically.
• Port - Specify the port or port range for the target. For some common service ports,
you can make use of the Common Service item above.
• Protocol - Here are three options, All, TCP and UDP. Select one of them from the
drop-down list for the target.
If the Website Domain is selected, you will see the following items:
• Domain Name - Here you can enter 4 domain names, either the full name or the
keywords (for example, Mercusys). Any domain name with keywords in it
(www.mercusys.com) will be blocked or allowed.
6. Click Configure in the Schedule column, you can select Any Time, or select Add to add a
new schedule. Then click Apply.
• Description - In this field, create a description for the schedule. Note that this
description should be unique.
• Time - Click and drag across the cells to set the effective time periods.
7. Click Save to complete the settings.
- 40 -
