MC³ 24.96.EX O&M Manual Page 42 08/14/01 4:34 PM/LDD
Logical Output Description
Manual Setpoint The Feedrate Setpoint Mode is “Man Spd”. See Feedrate
setpoint on page 16.
Z Tracking High The Zero Tracking load has stepped out of the load limit. See
Zero Tracking Parameters on page 28.
PID off Limits The output from the PID controller algorithm is greater than
99.995% or is less than .005%. See PID Parameters & Output
Dynamic Protection on page 25.
Master Com Lost Communications has timed out. See Communication Time-out
on page 45.
Belt Slippage The two tachos do not comply. See Tachometer Parameters
on page 29.
Always On Output is always ON ( closed ).
Always Off Output is always OFF ( open ).
Restr. Access Indicates restricted access to registers for communications
and the register editor. See also the “Extended Access” logical
input in List of Logical Inputs on page 37.
In Menu System The controller is in one of the SET or ACT menus.
High Speed Limit The belt speed is above the High Speed limit. See Limit
Switches on page 26. Action is delayed according to the High
Speed Delay parameter.
Low Speed Limit The belt speed is below the Low Speed limit. See Limit
Switches on page 26. Action is delayed according to the Low
Speed Delay parameter.
Discharge Gate This output is used to control the discharge, ahead of the
feeder, gate for batching.
Batch Running On when a batch in running.
Batch Pause On when the batch has been paused.
Batch Complete On when the batch has been completed.
Batch Error On when there has been an error in the batch process, either a
time-out or a batch under- or overweight. See Batch
Parameters on page 15
Serial Setpoint The Feedrate Setpoint Mode is “RM Serial”. See Feedrate
setpoint on page 16.
AIN1 High Alarm No useful function. Do not use.
AIN1 Low Alarm No useful function. Do not use.
AIN2 High Alarm No useful function. Do not use.
AIN2 Low Alarm No useful function. Do not use.
Inferred Speed The speed used by the controller is inferred, either because
the tacho mode is set to Simulator, or Auto-Bypass mode and
there is a tacho discrepancy condition. See Tachometer
Parameters on page 29.
List of Physical Outputs
Physical Output Description
