MC³ 24.96.EX O&M Manual Page 72 08/14/01 4:34 PM/LDD
SPARE PART LIST
This section contains a typical parts lists to assist you in identifying necessary parts, should a
problem develop with your MC
³
Controller unit or a part become lost or damaged. Depending on
the options ordered with your unit, it is possible that not all parts shown will be present in your unit.
If you need further assistance, or would like to place a parts order, please contact the Merrick
Spare Parts Department.
MC³ CONTROLLER SPARE PARTS LIST
Description Part Number
Power Supply Assembly BMKM21912-1A
Fuse BMKQ-73
CPU Board BMKM21746-1A
HPAD Board #1 BMKM21701-1A
HPAD Board #2 BMKM21701-2A
PCIO Board #1 BMKM21735-1A
PCIO Board #2 BMKM21735-2A
LTI Board BMKM21689-1A
Display Assembly BMKM21729-2A
ACCESSORIES FOR THE MC³ CONTROLLER
I/O System
Description Part Number
Backplane Board BMKM21882- 1
Cable - 9 inch BMKM20184- 6
Cable 12 inch BMKM20184- 5
Cable 18 inch BMKM20184- 3
Cable 22 inch BMKM20184- 4
Spare I/O Plugs
Description Part Number
4 Pin BMK09-204-40401
6 Pin BMK09-204-40601
8 Pin BMK09-204-40801
11 Pin BMK09-204-41101
Miscellaneous
Description Part Number
Grounding Bar BMKFE11887
Power Cord BMKFE11270
