23.
Programming The Oven Cycles And Set Up D4 and M1 (display on gantry) – Plate Warmer & Ambient option
Access the Set up Programming Mode
• Simultaneously firmly press cycle 1 and cycles 2 and 3 touch pads, press the “ON” touch pad and “P” appears on window
1. Release cycle 1, 2 and 3 and immediately (within 5 seconds) enter the programming code
• Pressing cycle 3 and cycle 2 then cycle 1 in quick succession.
• If any errors have been made in the above procedure, the panel will revert to its normal operating mode. If these
instructions have been carried out correctly “0” will appear on display 1.
• Please note that the default settings may vary depending on the issue date of the Eprom.
FUNCTIONS GROUPS VALUES
and Default Individual Permissible
SUB GROUPS Settings Settings Range °C ; °F
Display 1 Display 2
0 °C-°F
You must keep Refrigeration/Plate Warmer pad pressed Together with Cycle 3 pad while in the 0 parameters
Plate Warmer Temperature
01
100 (212)
030 ⇔ 110 ; 086 ⇔ 230
Heated Top plate ** (DO NOT ALTER)
02
80 (176)
030 ⇔ 080 ; 086 ⇔ 176
Plate Warmer touch pad
03
01
000 (off) ⇔ 001 (on)
Heated Top Plate
04
01
000 (off) ⇔ 002 (on)**
Cold Light touch pad
05
01
000 (off) ⇔ 001 (on)
Touch Pad Lock
07
00
000 (off) ⇔ 001 (on)
System Settings
Temp. (°C or°F)
08
00
000 (°C) ⇔ 001 (°F)
**If set to 000 (off), the heated top plate touch pad is disabled. If set to 001 (on) permits the top plate to be selected in the
split mode with only the left-hand half of the top plate working or the full mode with both halves of the top plate working
as one. If set to 002 (on) permits the top plate to be selected only in the full mode with both halves of the top plate working
as one.
1
Release Refrigeration pad Press Cycle 3 Each Time to Continue
Oven Set Temp. 11 140
000 ⇔ 180
Total Cycle Time 12 045
003 ⇔ 099 Minutes
Ventilation Temp. 13 80
Oven set temp.-1°
Cycle 1
Ventilation Time**** 14 002
0 minutes ⇔ cycle time
2
Press Cycle 3 Each Time to Continue
Oven Set Temp. 21 140
000 ⇔ 180
Total Cycle Time 22 045
003 ⇔ 099 Minutes
Ventilation Temp. 23 80
Oven set temp.-1°
Cycle 2
Ventilation Time**** 24 002
0 minutes ⇔ cycle time
3
Press Cycle 3 Each Time to Continue
Oven Set Temp. 31 140
000 ⇔ 180
Total Cycle Time 32 045
003 ⇔ 099 Minutes
Ventilation Temp. 33 80
Oven set temp.-1°
Cycle 3
Ventilation Time**** 34 002
0 minutes ⇔ cycle time
4
Press Cycle 3 Each Time to Continue
Oven Set Temp. 41 80
000 ⇔ 180
Oven Cycle Settings
Maintaining
Cycle
Total Cycle Time 42 030
000 ⇔ 099 Minutes
**** Maximum ventilation time is the total oven cycle time less one minute.
Press the Off pad
The above table summarises both the range of values that can be modified and the pre-set default values of software D4D and
D4U Eproms + M1D Eprom. The default settings remain in the memory even if the microprocessor batteries become
discharged.
