MI 3115 PV Analyser
Instrument operation
30
Parameters of PV module
Name
PV module name
For more information see PV module configuration.
Manufacturer
PV module manufacturer
Long name
PV module long name
Pmax
Nominal power of PV module
Umpp
Voltage at maximum power point
Impp
Current at maximum power point
Uoc
Open-circuit voltage
Isc
Short-circuit current
NOCT
Normal operating cell temperature
Alpha
Temperature coefficient of Isc (A/°C)
Beta
Temperature coefficient of Uoc (V/°C)
Gamma
Temperature coefficient of Pmax (%/°C)
Rs
Serial resistance of PV module
4.10.3 Import of list of PV modules
The list of PV modules can also be prepared in Metrel ES Manager and imported to the
instrument. Refer to Metrel ES Manager Instruction manual for detailed information.
WARNING
• After upload, list of PV modules on instrument will be overwritten!
