MI 3115 PV Analyser
Single tests
37
6 Single tests
6.1
In single test main menu two modes for selecting single tests are available.
Groups
View groups of similar tests
Last used
View last made measurements
6.2
In the Single test screens main measuring results, sub-results, limits and parameters of the
measurement are displayed. In addition, on-line statuses, warnings and other information
are displayed.
1
Name of single test function
2
Options
3
Terminal voltage, statuses, info, warnings
4
Parameters (white) and limits (red)
5
Sub-result
6
Main result
7
Graph
