2 Overview of the instrument
858 Professional Sample Processor
￭￭￭￭￭￭￭￭
11
Figure 5 Attaching a sample rack
Certain sample racks have a handle with a fixing screw. With this, the rack
can be fixed on the turntable by rotating in clockwise direction.
NOTICE
After the sample rack has been attached, the rack must be initialized
with the Rack initialization function in the control software ("Manual
Operation"), so that the magnet code of the rack can be recognized.
Automatic recognition of the rack type is only possible when the rack is
rotated into the starting position.
Recommended sample racks for the 858 Professional Sample Processor:
Qty.
Order no. Description
6.2041.440 Sample rack 148 x 11 mL
Sample rack for 148 samples at 11 mL with 3 rinsing beakers
Outer diameter (mm): 420
Hole diameter (mm): 17 / 68
6.2041.760 Sample rack for IC Sample Processor, 54 x
11 mL + 1 x 300 mL
Sample rack with small diameter for 54 x 11 mL sample vessels in
two rows and additionally 1 x 300 ml bottle
Outer diameter (mm): 270
Hole diameter (mm): 17 / 68
