3 Installation
858 Professional Sample Processor
￭￭￭￭￭￭￭￭
35
MSB
Stirrer / Ti Stand
Dosino
Remote Box
Dosino
Dosino
Relay Box
Ti Stand / Stirrer
Figure 32 MSB connections
The control instrument determines which peripheral devices are suppor-
ted.
NOTICE
When connecting MSB devices together, the following must be
observed:
￭ Only one device of the same type can be used at a single MSB con-
nector at one time.
￭ The MagIC Net software supports only dosing devices of the 800
Dosino type.
CAUTION
Exit the control software before you plug in MSB devices. When it is
switched on, the control instrument automatically recognizes which
device is connected to which MSB connector. The operating unit or the
control software enters the connected MSB devices into the system
configuration (device manager).
MSB connections can be extended with the 6.2151.010 cable. The maxi-
mum connection length permitted is 15 m.
