6 Appendix
858 Professional Sample Processor
￭￭￭￭￭￭￭￭
45
6 Appendix
6.1 Remote interface
The 6.2148.010 Remote Box allows devices to be controlled which cannot
be connected directly to the MSB interface of the Sample Processor.
Figure 39 Connectors of the Remote Box
1
Cables
For connecting to an MSB connector of the
Sample Processor.
2
MSB connector
Metrohm Serial Bus. For connecting external
dosing devices or stirrers.
3
Remote connector
For connecting instruments with a remote
interface.
6.1.1 Pin assignment of the remote interfaces
Figure 40
Pin assignment of remote socket and remote plug
The above figure of the pin assignment of a Metrohm remote interface
does not only apply for the Remote Box, but also for all Metrohm devices
with 25-pin D-Sub remote connectors.
