3.4 Mounting the retaining plate
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
18
￭￭￭￭￭￭￭￭
858 Professional Sample Processor
￭ Connect the power cord to the power grid.
3.4 Mounting the retaining plate
When removing samples from sealed vessels with the needle, the
6.2064.000 retaining plate is used for stripping vials while the lift is mov-
ing upward.
Figure 11 Mounting the retaining plate
1
Mounting the retaining plate
Fix the plate to the front of the tower with the four hex screws provi-
ded. The hex key required is part of the accessories.
3.5 Mounting a filtration cell holder or Dosino holder
Figure 12
Installing the filtration cell holder / Dosino holder
The filtration cell holder (6.2057.030) or the Dosino holder (6.2057.040)
can be mounted on the side wall of the tower, see above.
