2 Installation
￭￭￭￭￭￭￭￭
9
Equipping the titration cell
6.1903.030
6.1464.320
6.2713.010
6.1437.000
6.0345.100
6.2713.020
6.1403.030
6.1448.020
6.2701.040
6.2713.000
6.0341.100
2
1
2
5
2
3
4
6
6.0344.100
Figure 6 Equipping the titration cell
Equip the titration cell as follows:
1
Place the 6.1903.030 stirring bar in the titration cell.
2
Cut the 6.2713.0x0 ground-joint sleeves to the correct length and
attach them to the ground joints of the inserts (electrodes, adsorber
tube, etc.).
Please take care to ensure that the edges of the ground-joint sleeves
are cut to size cleanly and that there are no fringes. The ground-joint
sleeves must not protrude at the lower edge of the ground-joint
opening.
3
Insert the 6.1403.030 adsorber tube into the generator electrode.
