Metrohm 917 Coulometer - Figure 10 Unscrewing the Protective Cap from the Generator Electrode; Figure 11 Screwing the Electrode Cable to the Generator Electrode

2.2 Setting up the titration cell for coulometry
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
16
￭￭￭￭￭￭￭￭
1
Figure 10 Unscrewing the protective cap from the generator elec-
trode
2
Tighten the 6.2104.120 electrode cable to the generator electrode.
2
6.2104.120
Figure 11 Screwing the electrode cable to the generator electrode
Connecting the electrode cable to the coulometer
1
Plug the electrode plug into the Gen. socket of the coulometer.
