Metso Automation MAX Controls Inc. • 277596 •
Chapter 2
Analog Input Modules
Isolated Input Module IOP301
Overview
This module, featuring 16 isolated input channels, can be configured for any
mix of voltage or current inputs. The current loop can be powered from a
field supply or from a system loop supply provided via the backplane edge
connector. For current inputs, this module is pin and function compatible
with the IOP302 input module.
LED Indication
A green LED, labeled Active at the bottom of the module front panel, is on
when system power is present and the module is communicating with the
