Digital Output Modules

Form A/B of Relay Module IOP351

Form C Relay Module IOP350

Metso Automation MAX Controls Inc. • 277596 •

10-7

Field Wiring For Redundant Modules with Common End Element

(+)

(-)

Primary

Relay Module

W1 – installed

(+)

(-)

Secondary

Relay Module

W1 – installed

Power

Source

Switched

Device
