metso automation maxPAC - IOP320 Module Specifications

Analog Output Modules
4-20mA Output Module IOP320
Metso Automation MAX Controls Inc. • 277596 •
6-5
Error Condition Code
RAM Test Failure (power-on) 0x22
CPU Stack Error (power-on) 0x23
CPU Error (power-on) 0x24
Checksum Error (power-on) 0x25
Interrupt Error (power-on) 0x26
FPGA Download Error (power-on) 0x32
Calibration Error (channel 1 to 8) 0x41 – 0x48
Module Specifications
Resolution 12 bits
Scan Rate 8 msec.
Temperature Sensitivity ±0.004% of reading/
o
C
±1.5uv/oC RTI
Accuracy ±0.1% of reading ± .05% of
span at 25
o
C
Span 4 to 20 mA.
Calibration Self-calibration on power up
with calibration jumper set
Load Impedance 0 – 800 Ohms
Input Power
(from 24V system supply)
175 mA
