Chapter 10
Digital Output Modules
Form A/B Relay Module IOP351
Form C Relay Module IOP350
Overview
These modules provide 16 Form A relays or 10 form C relays. The form A
outputs can be converted to form B via on-board jumpers.
LED Indication
Individual red front-panel LEDs provide the output status indication for each
channel. A green LED, labeled Active at the bottom of the module front
panel, is on when system power is present and the module is communicating
with the DPU. This LED blinks on and off when the module is not being
scanned by the DPU.
