maxPAC Hardware Reference Guide
Metso Automation MAX Controls Inc. • 277596 •
4-4
Diagnostics
The module executes diagnostics on power up. When an error is detected on
power-up or during online operation, the front-panel green LED, labeled
Active, blinks the first digit at a slower rate and the second digit at a faster
rate. During normal operation the active LED is on continuously or flashes at
a steady one-second rate when the module is not being scanned. The
diagnostic codes are as follows:
Error Condition Code
A/D send fault 0x12
A/D receive fault 0x13
A/D self calibration failure 0x14
Bad A/D communication 0x15
A/D does not complete conversion 0x16
RAM Test Failure (power-on) 0x22
CPU Stack Error (power-on) 0x23
CPU Error (power-on) 0x24
Checksum Error (power-on) 0x25
Interrupt Error (power-on) 0x26
FPGA Download Error (power –on) 0x32
Module Specifications
Resolution 15 bits plus sign
Scan Rate 8 points converted in 1.6 seconds
Temperature Sensitivity ±0.004% of reading/
o
C ±1.5uv/
o
C RTI
Accuracy ±0.15% of reading ±0.5
o
C
Input Multiplexer Solid-state FET, optical isolation
Conversion method Sigma Delta oversampling
Linearization Digital in DPU. RTD ranges may be randomly
mixed.
Calibration Self-calibration on power up. Periodically on
line to compensate for temperature effects.
Maximum Lead Resistance
Compensation
5 Ohms each lead
Backup Conversions disabled if common RTD is
connected to redundant modules.
Conformity Error ±0. ±0.3
o
C, ±0.5
o
F
Normal Mode Rejection 60db @ 50/60 Hz
Common Mode Rejection 120db @ 50/60Hz, 100 Ohm imbalance
Common Mode Voltage 240V rms, 350V dc peak
Input Power
(from 24V system supply)
125 mA
