maxPAC Hardware Reference Guide
Metso Automation MAX Controls Inc. • 277596 •
9-4
Error Condition Code
RAM Test Failure (power-on) 0x22
CPU Stack Error (power-on) 0x23
CPU Error (power-on) 0x24
Checksum Error (power-on) 0x25
Interrupt Error (power-on) 0x26
FPGA Download Error (power –on) 0x32
Module specifications
Input voltage 24V, 48V jumper selectable
Input thresholds 24V – 10 Volts
48V – 20 Volts
Debounce 0-255 msec dynamically configured per
channel
Accuracy 1 cycle or ±0.15%, whichever is greater
Maximum frequency 32KHz
Minimum Pulse Width 10 usecs
Common Mode Voltage 240Vac rms, 350V dc peak
Input Power
(from 24V system supply)
150 mA
