CDP301 Dew-Point Tester User’s Manual
44 97585 Issue 1, June 2020
APPENDIX A
A.1 Dimensions
DRAWN
CHECKED
ENG APPR
MGR APPR
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN MILLIMETERS
ANGLES ±X.X°
2 PL ±X.XX 3 PL ±X.XXX
NAME
adam.harley
DATE
06/26/20
Solid Edge
TITLE
SIZE
A2
DWG NO REV
FILE NAME: Images for Steve .dft
SCALE: WEIGHT:
SHEET 1 OF 1
GAS INPUTGAS OUTLET
82.5
238 DIA
278
FLOW RESTRICTOR
BREATHER
1/8"FNPT INTO
FLAME ARRESTOR
1/8" FNPT INTO FLOW RESTRICTOR
EARTH/GROUND
CONNECTOR
