MICRODOS Pooltec - Auxiliary Outputs Configurable Types; Timer Type

Installation, Programming and Maintenance Microdos Pooltec
Rev. 1.0 EN
34
4.5.3.6. AUXILIARY OUTPUTS CONFIGURABLE TYPES
4.5.3.6.1. TIMER TYPE
Configure up to 3 daily timers to program the activation of the output.:
Activates/deactivates the
OUTPUT function.
• OFF: the recirculation pump activation follows its program operation.
• ON: the recirculation pump activates when this TIMER OUTPUT is activated.
NOTE: if the recirculation pump has NO PROGRAM:
• PUMP OFF: setting means that this timer output is independent from the General FLOW,
•
PUMP ON: setting means that this timer output can activate only when the General FLOW is OK.
Inside this menu you can
set up the functioning of
Px configurable
POWERED OUTPUTS.
Inside this menu you can
set up the functioning of
Dx configurable
DRY CONTACT OUTPUTS.
