4.5.3.8. CONFIG MENU
NOTE:
To configure these output types, please consult your Installer.
Inside this menu you can display the setup of the configurable Inputs and Outputs.
No changes are allowed to the user inside this Menu. Modifications are only allowed to the
Installer (INSTALLER PASSWORD required)
It is possible to rename all the
INPUTS and the OUTPUTS
The installer can change
his password
Define the INPUT
TYPE, to choose
between:
• NOT SET
• AL.P1
• AL.P2
• AL.P3
• AL.P4
• AL.D1
• AL.D2
• ALERT
• GENERAL
It is possible to define the
OUTPUT TYPE to choose
between:
• TIMER
• REPEAT
• pH
• Rx
• CL
• TEMP
• MICRODOSE
Defines if the INPUT
functioning is:
Normally Open (N.O).
Normally Closed (N.C).
